GRIPfit push-in fittings Series 7000 – Beverage and Water filtration
Tube external diameters: 4, 6, 8 mm
Fittings threads: ISO-228 BSPP (G1/8, G1/4, G3/8).
Fittings threads: ISO-228 BSPP (G1/8, G1/4, G3/8).
Series 7000 Beverage and Water filtration is a new range of push-in fittings made of reinforced bio-sourced technopolymer and low lead brass.
Thanks to the materials and new connection technology, these fittings are ideal for beverage dispensing and water filtration systems.
Thanks to the materials and new connection technology, these fittings are ideal for beverage dispensing and water filtration systems.
General Data
| Diameter | Ø4 mm | Ø6 mm | Ø8 mm | |
| Maximum working pressure | – 20° / + 40° + 40° / + 70° + 70° / + 100° | 16 bar 16 bar 16 bar | 16 bar 14 bar 12 bar | 16 bar 12 bar 10 bar |
| Minimum working pressure | -0,9 bar | |||
| Temperature | -20 ÷ +100 (see characteristics of tubes used) (NSF 61 requirement up to 82°C) | |||
| Storage temperature | -10° ÷ +60° | |||
| Threads | GAS cylindrical ISO-228 BSPP | |||
| Connecting tube | Polyurethane (PU), Polyethylene (PE), Polyamide (PA), Fluoropolymer (PTFE), Polyester (HY3L), rigid metal pipe with smooth grooved metal end | |||
| Fluid | Drinking and mains water, beverages and gas (for other fluids consult our technicians) | |||
| Materials | (A) Body = Technopolymer (PA11), low lead brass (CW510L) (B) Button = Technopolymer (PA66) (C) Gripping ring = Stainless steel (AISI 301) (D) Seals = EPDM (E) Thread = Low lead brass (CW510L) | |||
