DIN-A-MITE® A
The DIN-A-MITE® A power switching device controller is designed and manufactured with quality features expected from Watlow. DIN-A-MITE A capabilities include single-phase zero-cross switching up to 25 amperes at 600VAC (see rating curve). A unique integrated design removes the guesswork associated with selecting a proper heat sink and adequate terminations for the application. DIN-rail and back panel mounting is standard on this family of power switching devices. The DIN-A-MITE is also mercury free. Variable time base, 4-20mA process control or VAC/VDC input contactor versions are available. All configurations are model number dependent and factory selectable. This power controller includes 200KA short circuit current rating (SCCR) tested up to 480VAC to prevent arc flash with required fusing.
Specifications
Description | Information |
TRU-TUNE®+ Adaptive Control | No |
Agency Approvals | UL® 508, C-UL®, CE, SCCR |
Ambient Operating Range | 80°C (176°F) |
Max Output | 25A |
Mounting | 1 |
Output Firing | Zero Cross |
Phase Configurations | 1 |
Profiling | No |
Warranty (Years) | 3 |
