EZ-ZONE® RM Rail Mount Controller
The EZ-ZONE RM controller simplifies thermal system management. The EZ-ZONE RM integrated controller family is comprised of six module types: an integrated on-off or PID control, monitoring and over/under temperature limit controller module, a high-density on-off or PID control module, a high-density limit-only module, an input/output (I/O) expansion module, a high-density monitor/scanner module and a data logging and field communications access module. A system is configured by connecting any combination of module types to address specific application needs. The EZ-ZONE RM is extremely flexible and scalable allowing mixing and matching of I/O to configure 1 to 152 control loops and up to 256 monitor points.
Specifications
Description | Information |
TRU-TUNE®+ Adaptive Control | Yes |
Agency Approvals | UL® listed, CSA, CE, RoHS, W.E.E.E., FM, SEMI F47-0200, Class 1, Div. 2 rating on selected models |
Alarms | Up to 24 per modules |
Ambient Operating Range | -18 to 65°C (0 to 149°F) |
Communication Protocols | Standard BusModbus® RTUModbus® TCP |
Control/Limit Loops | 152/192 |
Description | Multi-loop controller with data logging ability |
Max Monitor Channels | 256 |
Max Output | 15A |
Mounting | DIN Panel Mount |
Operating Requirements | None |
Phase Configurations | 1 |
Profiling | Yes |
Supported Controllers | EZ-ZONE RM |
Remote Limit Reset | 1 |
Display Height | Optional RUI: 0.84in. (21mm) |
Warranty (Years) | 3 |
