Compact parallel grippers with T-guide Series CGSP
Single and double acting, magnetic, self-centering
Sizes: 20, 25, 32, 40
Sizes: 20, 25, 32, 40
Series CGSP grippers, available in 4 sizes (20, 25, 32 and 40) are parallel and double acting, self-centering and guided by means of a T-shaped sliding guide. Thanks to the materials and surface coating used, the gripper offers a high reliability. Moreover, the internal force transmission system is protected against the entrance of impurities by means of a steel cover so the gripper can also be used in dusty environments.
Extreme compact dimensions, a light design and high positioning repeatability make this series of grippers particularly suitable for handling small items, even if high operating frequencies are required.
Typical applications are pick & place, insertion, machine tending in the electronic components assembly sector, cosmetics & medical industry or in food packaging.
General Data
| Type of construction | Self-centering parallel gripper with T-guide |
| Operation | Single acting (NO, NC), double acting |
| Bores | Ø20, 25, 32, 40 mm |
| Force transmission | Lever |
| Air connections | M3 (Ø20, 25), M5 (Ø32, 40) |
| Working temperature | 5°C ÷ 60°C |
| Storage temperature | -10°C ÷ 80°C |
| Max. use frequency | 3 Hz (ø20, 25, 32), 2 Hz (ø 40) |
| Repeatability [% FS] | 0,02 mm |
| Interchangeability | 0,1 mm |
| Medium | Filtered air in class 7.4.4 according to ISO 8573-1. In case lubricated air is used, we recommend ISOVG32 oil and to never interrupt lubrication |
| Lubrication | After 10 million cycles, grease the sliding zones using Molykote DX grease |
| Protection class | IP 40 |
| Compatibility | ROHS Directive |
| Certifications | ATEX (II 2GD c IIC 120°C(T4)-20°C≤Ta≤80) |
| Materials | PTFE, Silicone and Copper free |
| Working pressure | Double acting: 2 ÷ 8 bar Single acting: 4 ÷ 8 bar |
N.B. Pressurize the pneumatic system gradually in order to avoid uncontrolled movements
Coding Example
| CGSP | – | 20 | – | NC | – | EX |
| CGSP | SERIES | |
| 20 | SIZES 20 25 32 40 | |
| NC | FUNCTIONING = double acting NO = single acting, normally open NC = single acting, normally closed | PNEUMATIC SYMBOLS PNZ1 PNZ3 PNZ2 |
| EX | CERTIFICATION = standard EX = ATEX certification |
