APT3100 Series
APT3100 is a high-performance compact pressure transmitter with a wide range of available measuring ranges, process connections, output signals, and electrical connections. It features high stability, strong reliability and anti-interference.
The model APT3100 for general industrial applications is the ideal solution for customers with demanding measuring requirements.
Features
- Dedicated high-performance ASIC regulating circuit
- Short response time
- Measuring ranges from 0-0.1~0-600 bar
- Output signal: 4-20 mA (2-Wire) or 1-5 VDC
- High accuracy of +/-0.20% of span
- Compact size to meet the needs of small space applications
- Multiple configurations to choose from for the best solution
Specification
| Process Fluid | : | Liquid, Gas, Vapor |
| Application | : | Absolute Pressure, Gauge Pressure, |
| Vacuum | ||
| Measuring Range | : | 0-0.1~0-600 bar |
| Accuracy | : | +/-0.45% of span (Standard) |
| : | +/-0.20% of span (Option) | |
| Non-Linearity | : | ≤0.2% of span (BFSL) (Standard) |
| : | ≤0.1% of span (BFSL) (Option) | |
| Non-Repeatability | : | ≤0.05% of span |
| Stability | : | ≤+/-0.2% of URL for 1 year |
| Working Temperature | : | -40~85 °C |
| Compensation Temp. | : | -10~70 °C |
| Temp. Effect of zero | ||
| Ranges≤0.25 bar | : | ≤0.4% FS / 10K |
| Ranges>0.25 bar | : | ≤0.2% FS / 10K |
| Temp. Effect of span | : | ≤0.2% FS / 10K |
| Over Pressure Limit | : | 250% of Full Scale |
| Vibration Resistance | : | 20 g (20-2000 Hz) per IEC 60068-2-6 |
| Shock Resistance | : | 100 g (10 ms) |
| EMI / RFI Effect | : | Follow SAMA PMC 33.1 from 20-1000 |
| MHz and for field strengths up to 30 V/m | ||
| Ambient Temperature | : | -20~70 °C |
| Humidity Limit | : | 0-95% Relative Humidity |
| Process Connection | : | G1/4″ (Standard) |
| M12 * 1.5, 1/4″-18 NPTM, 1/8″-27 NPTM, | ||
| 7/16″-20 UNF (Female) etc. (Option) |
| Pressure Port | : | 3.0 mm |
| Response Time | : | ≥1 ms |
| Output Response Time | : | ≤8 ms |
| Current Output | : | 4-20 mA (2-Wire) |
| Load | : | ≤ (VDC-9) / 0.02A |
| Voltage Output | : | 1-5 VDC (3-Wire) |
| Load | : | > 5000 ohm |
| Power Supply | : | 9-32 VDC |
| Material | ||
| Connection | : | Stainless steel 304 |
| Diaphragm | : | Stainless steel 316L |
| Body | : | Stainless steel 304 |
| Fill Fluid | : | Silicone Oil |
| Wetted O-ring (inside) | : | Viton |
| Seal Gasket (outside) | : | NBR |
| Electrical Connector | ||
| Cable Outlet | : | 2/3-Cable, Standard Outlet Cable 0.5 m |
| Packard | : | 3-Pin, Standard Outlet Cable 1 m |
| DIN EN175301-803A | : | 3-Pin, PG9, Without Outlet Cable |
| M12 * 1 | : | 4-Pin, Standard Outlet Cable 1.5 m |
| Protection Class | : | IP54 (Packard) |
| : | IP65 | |
| Intrinsically Safe | : | Ex ia IIC T6 (Standard) |
| Weight | : | Approx. 80 g |
