T760 Series_Remote reading thermometer with electrical contact
Service intended
Contact type temperature gauge is installed with electrical contact actuated by pointer. It provides the function which electrical circuit can be opened or closed by manual setpoint. It is applicable where signal is required (Audible or visual alarm) for control of resistance or any other application with auxiliary relay and contact.
| Nominal diameter | 100 mm |
| Accuracy | ±2.0 % of full scale |
| Measuring system (SAMA class ⅢB) | Organic gas : 0 ~ 200 °C Inert gas : -200 ~ 700 °C |
| Working range | Maximum scale value |
Standard features
| Location of stem and mounting | Bottom connection,surface, case mounting Lower back connection, flush, case lower mounting Lower back connection, flush, case center mounting |
| Case | 304SS |
| Cover | 304SS |
| Capillary | Capillary : 1.6/0.2 mm, 316SS Armored tube : 7.5/5.5 mm, 304SS |
| Window | Acrylic |
| Dial | White aluminium with black graduations |
| Contacts | Maximum voltage : 250 V AC Contact rating : AC 220 V, 0.25 A DC 100 V, 0.5 A With max. no of contact : 2 sets per gauge |
| Pointer | Black finished brass |
| Stem | 8.0, 10.0 and 12.0 mm 316SS and 316L SS |
| Stem, process connection | ⅜”, ½”, ¾” PT, NPT and PF |
| Option | ±1.0 % of full scale |
