R820 Series_Intrinsic safety type stator winding RTD
Service intended
The purpose of the stator winding RTD is to mainly detect and prevent overheating of motors. It is inserted in between a stator and a slot to measure a temperature. Stator winding RTD uses the phenomenon of changing electric resistance to measure a temperature. Since it has high stability and sensitivity, it is used to measure a temperature precisely. Also, it is made of a nonmetallic material, and therefore it has a structure of protecting element. It is designed to get flexibility and endure vibration and high pressure.
Standard features
| Body material | High temperature epoxy glass |
| Temperature limit | Class F : 155 ℃ (311 ℉) Class H : 180 ℃ (356 ℉) |
| Lead wires | 3 wire or 4 wire, copper, AWG #24 (With FEP or polyimide insulation) |
| Ambient temperature | Tamb = -40 ~ 80 ℃ : T6 Tamb = -40 ~ 130 ℃ : T4 Tamb = -40 ~ 95 ℃ : T5 Tamb = -40 ~ 180 ℃ : T3 |
| Working temperature | -50 ~ 180 ℃ |
| Standard | Explosive atmospheres. Equipment. General requirements ■ IEC 60079-0 / EN 60079-0 Electrical apparatus for explosive gas atmospheres. Intrinsic safety “i” ■ IEC 60079-11 / EN 60079-11 |
| Certificates | KCS Ex ia IIC T6…T3 ATEX II 1G Ex ia IIC T6…T3 Ga IECEx Ex ia IIC T6…T3 Ga ECAS Ex ia IIC T6…T3 Ga |
