R231, R232_Sanitary resistance temperature detector
Service intended
Sanitary RTDs can measure temperature from -50 to 200 °C. These sensors are available in Tri-clamp design with the immersion length from 50 to 250 mm. The wetted part of this assembly is polished to exceed No.4 minimum finish which is required by 3-A sanitary council standard #74-06.
| Element | Pt 100 Ω at 0 ℃ TCR : 3,850 ppm/k |
| Tolerances on temperature reading | Class A : ± (0.15 + 0.002 l t l) Class B : ± (0.3 + 0.005 l t l) * t : Reading temperature (℃) |
| Element and lead wire configurations | Single element : 2, 3 and 4 wire Double element : 4 and 6 wire |
Standard features
| Head type | Weatherproof (ALDC) Weatherproof (304SS) |
| Stem material | 304SS, 316SS, 316L SS |
| Process connection | Tri – clamp connection 1, 1½ and 2S |
