Pressure microregulators Series T
Ports G1/8 and G1/4
Series T pressure regulators are available with G1/8 and G1/4 brass connections.
A self-relieving piston has been incorporated into the design to allow decreasing adjustments.
Non-relieving versions are also available.
A self-relieving piston has been incorporated into the design to allow decreasing adjustments.
Non-relieving versions are also available.
All models are equipped with a by-pass valve which is useful when a regulator should be inserted between the valve and cylinder (or capacity) without any negative influence on the exhaust.
General Data
| Construction | Piston |
| Materials | Technopolymer body and piston, stainless steel spring, brass inserts, nbr o-ring and poppet |
| Ports | G1/8 – G1/4 |
| Weight | 95 g |
| Pressure gauge ports | G1/8 |
| Mounting | In-line or panel mounting (in any position) |
| Operating temperature | -5°C ÷ 50°C (with the dew point of the fluid lower than 2°C at the min. working temperature) |
| Inlet pressure | 0 ÷ 12 bar |
| Outlet pressure | 0.5 ÷ 10 bar (standard) 0.5 ÷ 2 bar 0.5 ÷ 4 bar 0.5 ÷ 7 bar |
| Nominal flow | See flow diagrams on the following pages |
| Secondary pressure (relieving) | With relieving (standard) without relieving (all regulators are provided with high relief flow vs function) |
| Fluid | Compressed air |
Coding Example
| T | 1 | 08 | – | R | 0 | 0 | 2 |
| T | SERIES | ||
| 1 | SIZE | ||
| 08 | PORTS: 08 = G1/8 | 04 = G1/4 | |
| R | REGULATOR | ||
| 0 | OPERATING PRESSURE: 0 = 0,5 ÷ 10 1 = 0 ÷ 4 |
2 = 0 ÷ 2 7 = 0 ÷ 7 (standard) | |
| 0 | DESIGN TYPE: 0 = self-relieving ; 1 = non relieving | ||
| 2 | MANOMETERS: ** = without pressure gauge (standard) 1 = with pressure gauge 0-2,5, with working pressure 0÷2 bar 2 = with pressure gauge 0-6, with working pressure 0÷4 bar | 3 = with pressure gauge 0-10, with working pressure 0,5÷7 bar | ** the pressure gauges are supplied dismantling manometers mod. M043-P .. |
