Nickel-plated dual seal super-rapid fittings Series H8000
Tube external diameters: 4, 6, 8, 10, 12 mm
Fittings threads: BSP (G1/8, G1/4, G3/8, G1/2)
Fittings threads: BSP (G1/8, G1/4, G3/8, G1/2)
Series H8000 fittings are designed to be used in particularly dirty and dusty working environments.
The patented system with double tightening on the tube guarantees a highly reliable connection and avoids any risk of leakage.
The special shape of the collar prevents the entry of impurities inside the fitting, guaranteeing performance over time, retention of the tube and easy connection and release.
Series H8000 fittings have a brass body, FKM seals for high temperatures (EPDM and NBR seals are also available) and can be used with pressures between -0.9 and 60 bar.
General Data
| Diameter | Ø 4, 6, 8, 10, 12 mm |
| Threads | Gas cylindrical ISO-228 (BSP) |
| Temperature [°C] | With FKM seals (standard): -15°C ÷ 200°C (dry air) With EPDM (upon request): -40°C ÷ 110°C With NBR seals (upon request): -20°C ÷ 80°C |
| Tube to connect | Polyamide (PA) 6 – 11 – 12, Polyurethane (PU), Polyethylene (PE), hytrel Polyester, PTFE and metal tubing (properly shaped) |
| Medium | All fluids compatible with the fitting materials requiring a leak-tight seal, e.g. water. For other fluids, please contact our technicians. |
| Materials | Body: nickel-plated brass Gripper: nickel-plated brass Seals: FKM (EPDM and NBR upon request) |
| Working pressure | -0.9 bar ÷ 60 bar The Series H8000 fittings can withstand a maximum pressure of 60 bar. However, the tube used might affect or limit the operating pressure considerably. |
