Intrinsically safe industrial measuring probe

This measuring probe has been designed for accurate and risk-free humidity monitoring in potentially explosive areas. It is mainly used in challenging industrial applications and under harsh conditions.

Category:

Technical data

General technical data
ApplicationPharmaceutical industry, petrochemical industry, food technology
VersionIndustrial version in wall design type (ATEX) with intelligent interchangeable probes
Outputs4 to 20 mA, (2 channels as optional extra)
Measurement mediumAir, compressed air, vacuum
Special featuresHousing with LCD display and operator panel; 5 probes with various process connections and cable 2 m, 5 m, or 10 m in length
Voltage supplyDC 24 V (via [Ex i] supply isolator or Zener barrier)
ApprovalsEx II 1 G Eex ia IIC T4 Ga (ATEX) Ex II 1 D IP65 T = 70 °C Da (with protective cover)
Sensing elementCapacitive (resistant to condensation, fast response)
Measuring rangeRH = 0 to 100 % RH, T = -40 to +180 °C (depending on type), available with the following as an optional extra: Td+a+x+Tw
Protection typeIP65 wall-mounted version (metal case)
