GRIPfit push-in fittings Series 7000 – Automation
Tube external diameters: 4, 6, 8, 10, 12, 16 mm
Fittings threads: ISO-965 Metric parallel (M5, M7, M10x1, M12x1,25),
ISO-7 BSPT (R1/8, R1/4, R3/8, R1/2),
ISO-228 BSPP (G1/8, G1/4, G3/8, G1/2).
Fittings threads: ISO-965 Metric parallel (M5, M7, M10x1, M12x1,25),
ISO-7 BSPT (R1/8, R1/4, R3/8, R1/2),
ISO-228 BSPP (G1/8, G1/4, G3/8, G1/2).
Series 7000 Automation push-in fittings are made of reinforced technopolymer to meet the new market demands for reliability, ease of use and efficient solutions.
Their compact dimensions and lightweight make this new range of fittings ideal for most pneumatic applications associated with optimum gripping and sealing technologies.
Their compact dimensions and lightweight make this new range of fittings ideal for most pneumatic applications associated with optimum gripping and sealing technologies.
General Data
| Diameter | Ø 4 mm | Ø 6 mm | Ø 8 mm | Ø 10 mm | Ø 12 mm | Ø 16 mm | |
| Maximum working pressure | – 20° / + 40° + 40° / + 60° + 60° / + 80° | 16 bar 16 bar 16 bar | 16 bar 14 bar 12 bar | 16 bar 12 bar 10 bar | 16 bar 10 bar 8 bar | ||
| Minimum working pressure | -0,9 bar | ||||||
| Temperature [°C] | -20 ÷ +80 (see characteristics of tubes used) | ||||||
| Threads | Cylindrical gas ISO-228 BSPP Conical gas ISO-7 BSPT (with pre-applied PTFE sealant) ISO-965 Metric parallel | ||||||
| Connecting tube | Polyurethane (PU), Polyethylene (PE), Polyamide (PA), Fluoropolymer (PTFE), Polyester (HY3L), rigid metal pipe with smooth grooved metal end | ||||||
| Fluid | Compressed air (for other fluids consult our technicians) | ||||||
| Materials | (A) Body = Technopolymer (PA66), Nickel-plated brass (B) Button = Technopolymer (PA66) (C) Gripping ring = Stainless steel (AISI 301) (D) Seals = NBR (E) Thread = Nickel-plated brass | ||||||
