APT9500 Series

The APT9500 Series is a transmitter of differential pressure flowmeter. Differential pressure can be converted into flow value via microcomputer technology and flowrate, totalizer. The differential pressure can be displayed directly in LCD screen. It’s equipped with

strong output function: 4-20 mA, pulse and HART. APT9500 is widely used in differential pressure sensors flowmeter such as orifice, venturi,annubar, v-cone etc. It has high stability and high accuracy.

Enquiry
Add to quote
Part Number: Category:

Features

  • Converter can be rotated at six directions for easy installation
  • Can display flow rate, totalizer and differential pressure at the same time
  • Two years stability of 0.2%
  • 0.075% accuracy
  • Parameter setting by keypad directly
  • 4-20 mA and pulse output, HART communication
  • Automatic zero calibration by press-button
  • Explosion Proof and weather proof housing
