Angle seat valves Series ASX

2/2-way – Normally Closed (NC) and Normally Open (NO)
2/2-way – Double Acting (DA)
Angle seat valves are available in different versions with regard to nominal diameter, type of fluid and process connections.
They are able to manage media that are corrosive or contain suspended solid particulate matter and can be used in applications with high operating temperatures.

The operation is determined by the pneumatic drive of a single acting, guided piston actuator with spring return.
There are also models available with double acting actuators, without spring.
For liquid media we recommend the models with flow direction under the seat.
For gas or steam we recommend the models with flow direction above the seat.

General Data

TECHNICAL FEATURES
Function2/2 NC – 2/2 NO – 2/2 Double Acting
OperationPneumatic, poppet type
Pneumatic connections1/4…4″ with BSP/BSPT/NPT threads, flanged, welding ends, tri-clamp
Nominal diameter Ø [mm]DN8…DN100
Flow coefficient Kv (m³/h)2,2…132
Operating pressure0 ÷ 2…16 bar
Operating temperature-10 ÷ 180 °C (standard seals) / 25 ÷ 220 °C (high temperature seals)
FluidWater, air, steam, inert or corrosive liquids and gases (compatible with the materials in contact)
Viscosity600 cSt. Max
InstallationIn any position
MATERIALS IN CONTACT WITH THE MEDIUM
Body316 stainless steel (DN8 ÷ DN80) / 304 stainless steel (DN100)
SealsPTFE
Internal parts316 stainless steel
SPECIFICATIONS PNEUMATIC ACTUATOR
Actuator dimensionsØ40, Ø50, Ø63, Ø90, Ø125 mm
Actuator material304 stainless steel / aluminium (only for Ø125 mm)
Piston materialAluminium
Piston seal materialFKM
Pilot fluidAir or inert gases
Piloting pressure10 bar max.
Actuator position360° rotatable

Coding Example

ASX21W015G104012
ASSERIES
XTYPE OF ACTUATOR
X = Metal actuator
2BODY MATERIAL
1 = 304 stainless steel (DN 100)
2 = 316 stainless steel (DN8 ÷ DN80)
1NUMBER OF WAYS – FUNCTIONS
0 = 2/2-way NO
1 = 2/2-way NC
3 = 2/2-way DA (Double Acting)
WFLOW DIRECTION
W = Under the seat (anti-water hammer)
Y = Above the seat
015NOMINAL DIAMETER
008 = DN 8
010 = DN 10
015 = DN 15
020 = DN 20
025 = DN 25
032 = DN 32
040 = DN 40
050 = DN 50
065 = DN 65
080 = DN 80
100 = DN 100 – only for flanged version with NC and DA function and pressure under the seat
G1BODY CONNECTION
G1 = BSP thread DIN 228-1
T1 = BSPT thread DIN 2999-1
N1 = NPT thread ASME B1.20.1
H7 = Welding ends DIN 11850-2 / DIN 11866-A
H8 = Welding ends DIN 11850-3
K7 = Tri-clamp ISO 2852
F2 = Flange DIN 2543
040ACTUATOR DIMENSION
040 = Ø40 mm
050 = Ø50 mm
063 = Ø63 mm
090 = Ø90 mm
125 = Ø125 mm
1ACTUATOR MATERIAL
1 = 304 stainless steel
8 = Aluminium
2SEALS
2 = For standard temperatures -10 ÷ 180 °C
3 = For high temperatures 25 ÷ 220 °C
OPTIONS
= None
PS1 = NPN type proximity switch – NO contact – 10 ÷ 30 V DC power supply
PS2 = PNP type proximity switch – NC contact – 10 ÷ 30 V DC power supply
PS3 = PNP type proximity switch – NO contact – 10 ÷ 30 V DC power supply
PS4 = NPN type proximity switch – NC contact – 10 ÷ 30 V DC power supply
PS5 = SCR type proximity switch – NO contact – 20 ÷ 250 V AC power supply
PS6 = SCR type proximity switch – NC contact – 20 ÷ 250 V AC power supply
SL1 = Stroke limiter for Ø50, Ø63 mm actuators
SL2 = Stroke limiter for Ø90 mm actuators
PI1 = Position indicator for Ø40, Ø50, Ø63, Ø90 mm actuators
PI2 = Position indicator for Ø125 mm actuators
